Description
Processor
-
ARM® Cortex®-A55 4Core up to 1.80GHz
Graphics
-
Mali™-G52-2EE Graphics
Memory
-
2GB DDR4
Storage
-
16GB/32GB eMMC Flash Internal Storage
-
1 x TF (MicroSD) reader, supports 128GB
Network
-
1 x Realtek® RTL8211F-CG Gigabit (10/100/1000 Mb/s) LAN
-
802.11ax WiFi6 + Bluetooth 5.0 Module
-
Wake on LAN
OS Support
-
Android 11
Video Output
-
HDMI 2.0, up to 4K @ 60fps
Audio Output
-
Rockchip RK809 HD Audio
-
Support for S/PDIF
-
2 x 3.5mm Analog Stereo Audio jacks
I/O Ports
-
1 x HDMI 2.0 port
-
1 x LAN port
-
1 x S/PDIF port
-
2 x 3.5mm Audio jacks
-
1 x DC-In 2.5mm Power Connector
-
2 x USB 2.0 ports (Side)
-
1 x USB 3.0 port (Side)
-
1 x MicroUSB port (Side)
-
1 x TF/MicroSD reader (Side)
Power Supply
-
DC12V 2A Power Adapter 2.5mm plug (UL/CE/FCC Certified)
-
Standard US Power Cord included, European Power Cord available as option
-
Powered by PoE supported
-
Energy Star Compliance, Idle mode at <1W
Supported Video Formats
-
DAT, MPEG, MPE, MPG, TS, TP, VOB, ISO, AVI, MP4, MOV, 3GP, FLV, MKV, M2TS, MTS, M4V, WMV, ASF, RM, RMVB
Supported Audio Formats
-
MP2, MP3, WMA, WAV, OGG, OGA, FLAC, ALAV, APE, AAC
Dimension
-
5.00 x 5.00 x 1.20 in (H)
